Marom Dolphin Wild Goose - A Personal Tactical, Military, Hunting, Hiking & Game Carrier Hauler with Wheels
Wild Goose Can be used as a:
crew-served weapons backpack hauler roller attachment
hiking backpack with wheels
tactical backpack with wheels
military backpack with wheels
hunting backpack with wheels
Deer Cart
hiking cart
Game Carrier
An innovative, hybrid electric powered tactical hauler. Hauls heavy loads over any terrain while maintain full combat effectiveness and mobility on the battlefield.
Offered in two main variants: 4x4 (load capacities up to 120Kg), 2x2 (load capacities up to 60Kg).
Designed to comply with military standards and ingress protection.
Component | Parameter | Conditions | MIN | TYP | MAX | Units |
Battery | Chemistry | Lithium-Ion | ||||
Voltage (nominal) | 36.5 | V | ||||
Current (Maximum) | 30 | 60 | A | |||
Capacity (nominal) | 22.8 | Ah | ||||
Pack Power | 832 | Wh | ||||
Operating Temperature | Charge: 45, Discharge: 70 | Celsius | ||||
Charge cycle | 500 | Cycles | ||||
Dimensions (LxWxH) | 215x165x72 | mm3 | ||||
Weight | 4 | 8 | 4.5 | Kg | ||
Motor | Configuration | Brushless DC Hub | ||||
Rated Power | 450 | W | ||||
Input Voltage | 36 | 48 | 60 | V | ||
Rated Current | 40 | A | ||||
Feedback | Hall effect sensors | |||||
Operating Temperature | With Ferrofluid applied | -25 | 90 | Celsius | ||
Ferrofluid Cooling | Low viscosity magnetically suspended fluids | |||||
Controller | Supply Voltage | 18 | 36 | 80 | V | |
Continuous Power | 3000 | W | ||||
Efficiency (servo drive) | >99 | % | ||||
Operating Temperature | -20 | 80 | Celsius | |||
Mechanical Shock (servo drive) | IEC60068-2-27 | 15G/11ms Half sine | ||||
Vibration (servo drive) | IEC60068-2-6 | 4G/10Hz:57Hz |
https://www.youtube.com/watch v=6DkQnUgg3Ok&feature=emb_title
Manufacturer | Marom Dolphin |
---|---|
Manufactured At | Israel |
Color | Black |
